Wilkins Pressure Reducing Valve With Integral Bypass Check Valve And Strainer
Product Code:
600HLR
Product Enquiry
To prevent automated spam submissions leave this field empty.

Tabs

Overview

The Wilkins Model 600HLR is designed for installation on potable water lines to reduce high inlet pressure to a lower outlet pressure. The integral strainer makes this device most suitable for residential and commercial water systems requiring frequent cleaning because of sediment and debris.

The direct acting integral bypass design prevents build-up of excessive system pressure caused by thermal expansion. The balanced piston enables the regulator to react in a smooth and responsive manner to changes in system flow demand, while at the same time, providing protection from inlet pressure changes.

PRODUCT FEATURES

  • Main valve body and cover made from cast Bronze.
  • Standard with 20 mesh stainless steel strainer.
  • Spring range 70 to 875kpa.
  • Factory preset at 350kpa.
  • Maximum working water pressure 2100kpa.
  • Maximum working water temperature 60°C.
