Backflow Prevention Assembly Test Kit
Product Code:
BF-TG3
Product Enquiry

Enquire about this product below

To prevent automated spam submissions leave this field empty.
To prevent automated spam submissions leave this field empty.

Tabs

Overview

The Model BF-TG3 backflow prevention assembly test kit is designed for testing all brands of pressure type vacuum breakers, double check valve, and reduced pressure principle backflow prevention assemblies.  The BF-TG3 is capable of performing all known testing procedures.

PRODUCT FEATURES

  • Gauge body is made from thermoplastic material.
  • Gauge dial 115mm in diamter 0-15psi scale.
  • Maximum working pressure 200psi.
  • Accuracy +/-0.2 psid (descending).
  • Valves are soft seated needle with replacable seats.
  • Hose and fittings (3) 125mm length, colour coded, SAE 45° flare fittings and 90 micron cleanable porous metal (brass) filters.
  • 5 year warranty against defects in materials and manufacturing.
  • Durable carrying case with external fitting compartment.
  • Quick Test fitting sets available as separate part for quick testing of assemblies.
  • Working temperature 1-65°C.
