Delabie Premix Comfort Thermostatic Mixing Valve
Product Code:
DE731xxx
Product Enquiry

Enquire about this product below

To prevent automated spam submissions leave this field empty.
To prevent automated spam submissions leave this field empty.

Tabs

Overview

Delabie Premix Comfort is a group thermostatic mixing valve for mixed water distribution from 32° - 42°C giving anti-scalding safety. The valves regulate temperature variations and are supplied with filters and non-return valves that can be accessed from the outside without removing the mechanism. Thermal shock with no specific lever needed (push-button on the control knob).

OPERATION AND APPLICATIONS

  • Maximum hot water temperature: 85°C
  • Differential hot water / mixed water: 15°C minimum
  • Pressure difference at the inlets: 1 bar maximum (0.5 bar recommended)
  • Minimum pressure / maximum: 1 - 10 bar (1 - 5 bar recommended)
  • Left hand side hot water inlet (red ring) and right hand side cold water inlet (blue ring)
  • Mixed water outlet at the top (purple ring)
  • For bottom outlet: unscrew / place lid at the top and outlet connector at the bottom
  • Maximum temperature limiter, can be adjusted by the installer
  • Reduced risk of scalding by limiting temperature at the point-of-use

Available in:

  • 3/4" -   DE731 002 (55L/min)
  • 1"  -     DE731 003 (90L/min)
  • 1 1/4" - DE731 004 (140l/min)
  • 1 1/2" - DE731 005 (190l/min)

This model valve is also available in a higher temperature setting of 44°-58°C, see list under the MODELS tab.
