The MacDonald universal trap is designed for our urinals with an a rear or downward outlet with volumes of between 2 - 4 L/min flow. The trap has a Ø50mm inlet that connects to the fixture outelt and a Ø50mm outlet that connects to a waste pipe. Comes with a plug for easy cleaning. This trap can also be used for wash basins where an inwall solution is required.
The ASI 0600 series mirror has a stainless steel inter-lok angle frame with either standard plate glass or tempered glass options. The 19x16mm frame is roll formed 18 gauge type 304 stainless steel angle has corners heliarc welded, ground and polished smooth to a uniform satin finish. The frame is formed seamless with mitred corners, welded, polished and have gently radiused edges to provide added strength and an appealing aesthetic. Mirror edges are protected with friction and chafe absorbing fillers.
ASI AS0828 Surface Mounted Waste Bin holds 25L of paper waste. Stainless steel with satin finish. Vertical front edges rounded to 13mm radius, no exposed fastening devices or spot welded seams, hemmed top lip for user safety. Four interior hooks for hanging a disposable bag (supplied by others).
Screw-mounted to wall through keyhole slots on the back of unit. Theft resistant after installation of concealed locking screw.
Franke DV-VR01-081 is a high security washbasin designed and tested to be vandal-proof and avoid ligature points wherever possible. A high-grade non-porous polyester gel coat surface in all white comes as standard. The gel coat has been specially formulated to resist chemicals and ultraviolet rays. This model is suited to combine with a MacDonald Security washbasin control set available in electronic or mechanical.
DELABIE DE49350015 is a wall-mounted electronic basin mixer with recessed water inlets and has 4 installation options; 1) recessed in concrete, 2) timber walls, 3) solid walls, and 4) through-wall installations. The very clever wall connection allows for connection to hot water and cold water pipes easily. Power can be either 230/6V mains power or 6V Lithium battery power (see models). The solenoid valve and tap body has low water stagnation for reduced risk of water–borne bacteria development. Flow rate is factory set at 3L/min @ 300kPa water pressure, can be adjusted from 1.5 – 6L/min.
Watts Eurotherm L117 is a thermostatic mixing valve designed to supply sinks and washbasins with tempered water not exceeding the set temperature (up to 5 washbasins depending on tap flow rate). This mixer is ideal for schools, restaurants, laboratories,, offices, correctional, etc...anywhere needing a supply of water at a pre-set temperature on site. Hot water supply cut totally and immediately is cold water supply is interupted.
PROTECTION AGAINST LEGIONELLA
Roval AS20031 is a semi-recessed mounted twin roll, toilet paper dispenser. The dispenser has a formed seamless, bowed front face with gently radiused edges to provide added strength and complimentary appearance. Fabricated in 0.9mm type 304 satin finish stainless steel. All exposed surfaces are protected with PVC film which is easily removed after installation. Includes semi-recessed flange for unit.
Franke EXOS Jumbo toilet roll holder for wall mounting, chromium nickel steel, with satin-finish and InoxPlus surface refinement for the reduction of finger marks making it easier to clean. Material thickness 1.2 mm, closed casing with inspection windows on the side, paper dispensed over two serrated tear-off edges, cylinder lock with Franke standard key, for one jumbo roll with a maximum diameter of 280 mm and a tube measuring 40 mm, includes mounting materials.
Dimensions 325 x 364 x 130 mm (W x H x D)
Sirrus TS1850 is a thermostatic shower mixer with dual control for both temperature and flow.
DELABIE DE20804T2 is a wall mounted electronic basin tap with independent IP65 electronic control unit and shock-proof infrared sensor. Available as 230/12V mains supply with transformer. Anti-bacterial duty flush operates for ~60 seconds every 24 hours after last use. Flow rate is limted to 5L/min at 300kPa. Operating pressure is 100-500kPa, 300kPa is recommended. Supplied with 2x removable chrome plated stainless steel spouts L. 188mm Ø 28mm. Base and spout with smooth interior and low volume of water (limits bacterial niches).
